TMC5160T Driver Bigtreetech stepper motor driver for 3D printer machine

TMC5160T Driver Bigtreetech stepper motor driver for 3D printer machine

• BIGTREETECH TMC5160T Driver is a high-performance stepper motor driver built for demanding 3D printer and CNC motion systems.
• Enables smooth, high-torque motion control and supports highly dynamic drives (including setups using external transistors).
• Delivers quieter operation with advanced control modes like stealthChop2 and spreadCycle for cleaner motion and reduced motor noise.
• Supports up to 256 microsteps for finer positioning, improved surface finish, and better detail on prints.
• Compact design makes it easy to integrate into upgrades and custom builds—ideal for makers and print farms in India.

Specifications

• Model: BIGTREETECH TMC5160T Driver
• Input Voltage: 4.75V to 46V
• Motor Phase Current: Up to 2.8A RMS (5A peak)
• Microstepping: Up to 256 microsteps per full step
• Interface: SPI, Step/Dir
• Operating Temperature: -20°C to +75°C

Dimensions

• Approx. Size: 20 mm × 25 mm

Applications

• High-torque axis upgrades for 3D printer machines
• CNC machines needing precise and dynamic motion control
• Robotic systems and automation projects using stepper motors
• Performance builds where smooth motion and torque stability are critical

Usage

• Install the TMC5160T driver on a compatible control board and connect the stepper motor and power per manufacturer guidelines.
• Choose integration mode: SPI (for tuning/monitoring) or Step/Dir (standard control).
• Configure features like stealthChop2 / spreadCycle in firmware for the best balance of noise, speed, and torque.
• Ensure adequate cooling and set current limits correctly for long, stable print sessions.

Protection Features

• Over-temperature protection
• Over-current protection
• Short-circuit protection

Package Include

• 1 piece of  TMC5160T V1.0.
