CNC Voron Tap V2 Red and Black

CNC Voron Tap V2 Red and Black

• The CNC Voron Tap V2 is a precision, all‑metal toolhead probing solution designed to improve first-layer accuracy and reliability on Voron 2.4 R2 and Voron Trident builds.
• Its lightweight construction and stable linear motion system deliver consistent probing and strong Input Shaper results.
• CNC-machined probe assembly built for high accuracy and repeatability
• Uses MGN7H linear guideways for a lighter, thinner setup vs heavier rail options
• Upgraded V2 sensor improves reliability with a wider voltage range (5–24V)

Specifications

• Product Name: CNC Voron Tap V2
• Material: CNC all metal (AL6061/SS304)
• Net Weight: 65g (including X-axis limit switch bracket)
• Sensor Type: Omron EE-SX4320
• Voltage: 5–24V
• Linear Guideways: MGN7H
• Compatibility: Voron 2.4 R2, Trident (with MGN12H X-axis rail), linear rails and lead screw

Applications

• More accurate Z probing for consistent first layers
• High-speed Voron builds where toolhead weight matters Voron 2.4 R2 probe
• Better motion tuning support with improved Input Shaper data

Features

• Feather light toolhead impact Voron Trident probe(lightweight body helps maintain precision)
• MGN7H is lighter and thinner while keeping strong rigidity
• Omron EE-SX4320 transmissive photomicrosensor for higher accuracy and reliability
• 5–24V support for flexible electronics integration
• Built with reputable linear components and sturdy limit assembly for long-term durability

Installation

• XY stroke: No XY adjustment needed (thickness similar to 2.4R2 X carriage)
• X-axis requirement: Needs MGN12 X-axis (not older MGN9 setups)
• Extruder mount: Replaces X-carriage; CW2-style mounting (LGX/Galileo mounts available)
• Bed stability: Probing force can be 500–800g—ensure the bed doesn’t move during probing
• Not recommended for Voron 1.8/Legacy/Switchwire
• If the bed moves when you firmly tap it, accuracy will suffer
